4591

2" Midrange Compression Driver

2″ Midrange Driver
Unique patented Design
118 dB sensitivity 1 W / 1 m
300 Hz Crossover
90 mm Voice Coil
8 or 16 Ohm

The BMS exclusive voice coil technology employs a light weight Copper Clad Aluminium wire wound inside and outsde of the Kapton™ former to improve the heat dissipation, dramtically increasing the acoustic output and reliability of the driver while minimising the power compression.

Specification

4591 Specification

Throat diameter:	2″ (50.8 mm)
Nominal impendance:	8 or 16 Ohm
Power capacity (AES):	150 W AES above 400 Hz
Peak Power:	1000 W peak above 500 Hz
max. SPL (cont.):	136 dB at 150 W
Sensitivity
1 W / 1 m:	118 dB
Frequency Range:	200 – 9000 Hz
Recommended Crossover:	300 Hz
min. impedance modulus:	8.3
Voice Coil Diameter:	3.5″ (90 mm)
Magnet Material:	Ferrite
Flux Density (Tesla):	1.95
Efficiency:	35 % (300 – 5000 Hz)
Voice Coil Material:	Copper Clad Aluminum
Voice Coil Former:	Kapton TM
Diaphragm Material:	Polyester
