Specification
8CN552 Specification
| Application | 2-way Transducer | |
| Nominal Impendance: | Ohm | 8 |
| Power handling AES noise: | W | 200 |
| Sensitivity (1 W / 1 m): | dB | 95.5 |
| Frequency response: | Hz | 70 – 3000 |
| Voice Coil Diameter: | mm | 52 (2″) |
| Voice Coil Material: | Cu | |
| Voice Coil Winding Depth: | mm | 15 |
| Magnet Gap Depth: | mm | 7 |
| Basket: | Cast Aluminum | |
| Voice Coil Inductance Le | mH | 0.179 (4 Ohm) |
Recommended reflex enclosure:
3 L / 115 Hz, BRD = 50 mm / 98 mm long
8 L / 85 Hz, BRD = 60 mm / 94 mm long
10 L / 66 Hz, BRD = 60 mm / 139 mm long
