| Application | Low-middle | |
| Nominal Impendance: | Ohm | 8 |
| Power handling AES noise: | W | 250 |
| Sensitivity (1 W / 1 m): | dB | 94 |
| Frequency response: | Hz | 80 – 3000 |
| Voice Coil Diameter: | mm | 52 (2″) |
| Voice Coil Material: | Cu | |
| Voice Coil Winding Depth: | mm | 19 |
| Magnet Gap Depth: | mm | 6.5 |
| Basket: | Cast Aluminum | |
| Effect. diaphragm diameter D | mm | 168 |
Recommended reflex enclosure:
1.9 L / 104 Hz, BRD = 30 mm / 77 mm long
3.8 L / 90 Hz, BRD = 40 mm / 86 mm long
| Resonance Frequency: | Fs | Hz | 82 |
| DC Resistance: | Re | Ohm | 5.8 |
| Mechanical Q Factor: | Qms | 4.8 | |
| Electrical Q Factor: | Qes | 0.45 | |
| Total Quality Factor: | Qts | 0.41 | |
| Equivalent Volume: | Vas | L | 9.7 |
| Moving Mass: | Mms | kg | 0.0266 |
| Mechanical Complience: | Cms | mm / N | 0.14 |
| BL Factor: | BL | Tesla m | 13.3 |
| Effective Piston Area: | Sd | m² | 0.0222 |
| Max. linear Excursion: | Xmax | mm | +/- 6.3 |
| Voice Coil Inductance: | Le1k | mH | 0.52 |
| Le10k | mH | 0.333 |
Frequency Response measured 100 W (28.3 V)
at 1 m in a closed enclosure of 25 litre in an anechoic chamber incl. 2nd and 3rd harmonic distortion raised 20 dB.
